QUALITY DEFINED
| Annular cutting | Ø 12 – 120 mm |
| Twist drilling | Ø 38mm |
| Countersinking | Ø 10 – 120 mm |
| Threading | M3 – M42 |
| Length | 440 mm |
| Width | 230mm |
| Height | 660-750mm |
| Stroke | 210 mm |
| Weight | 33 kg |
| Magnet (l x w x h) | 330 x 110 x 60mm |
| Magnetic force | 24000N |
| Motor power | 1800W |
| Total power | 2050 W |
| Speed (no load) | 82/180/245/535rpm |
| Speed (load 1800 W) | 65/135/185/400 rpm |
| Spindle | MT4 /MT3 [19,05 mm/31.75mm] |
| Voltage | 110 – 120 V / 60 Hz 220 – 240 V / 50 – 60 Hz |
STROC.120 MAGNETIC DRILL Ø120MM W/TAPPING
MORSE TAPPER 4
The powerful Macstroc STROC.120 Magnetic core drilling machine cuts holes up to ø120 mm (4- ¾”) and it’s reverse function helps for tapping. The STROC.120 has 1800W Motor with 4 speed adjustments. The MT-4 arbor is useful to use bigger diameter of twist drills directly to the machine, and the depth of drilling can be adjusted to below magnetic base.
